The Castle M-CC060-0064-00 2028-800kV sensored brushless motor for 1/5 scale vehicles is engineered to deliver uncompromising torque, cooler running temperatures, and unmatched durability for large-scale RC platforms. Designed for extreme performance, this motor features a robust 4-pole, 12-slot inrunner architecture and dual sensor ports for flexible installation. Whether you're converting gas-powered vehicles or upgrading electric builds, the Castle M-CC060-0064-00 large-scale motor with Kevlar wrap and neodymium magnets is built to withstand the demands of 2WD and 4WD setups weighing up to 30 lbs and 25 lbs respectively. With burst outputs reaching 10 horsepower, this motor is a powerhouse for serious RC enthusiasts.
Key features of the Castle M-CC060-0064-00 2028-800kV motor
- Dual-mode operation – sensored startup and ultra-efficient sensorless running
- Kevlar-wrapped rotor – reinforced for structural integrity under extreme loads
- Neodymium magnets – high-temperature grade for sustained torque delivery
- Vibration dampening – protects oversized NMB bearings for extended life
- Low-resistance stator – cooler operation under heavy throttle conditions
- Dual sensor ports – flexible mounting options for large-scale chassis
How does dual-mode operation enhance performance?
The Castle M-CC060-0064-00 4-pole motor with dual sensor ports and 8mm bullet connectors offers both sensored and sensorless running modes. At startup, the motor uses sensor feedback to eliminate cogging and deliver smooth, torque-rich launches. Once in motion, it transitions seamlessly to Castle’s ultra-efficient sensorless mode, where electronic timing adapts to load conditions. This hybrid approach ensures optimal power delivery and thermal efficiency across all driving phases, making it ideal for high-demand 1/5 scale applications.
Why is the Kevlar wrap critical for rotor integrity?
The rotor in the Castle M-CC060-0064-00 large-scale motor with Kevlar wrap and neodymium magnets is reinforced with high-strength Kevlar to prevent deformation under extreme centrifugal forces. This structural reinforcement is essential for motors operating in the 10HP burst range, where rotational stress can compromise performance. Paired with high-temperature neodymium magnets, the rotor maintains magnetic integrity and mechanical stability even during aggressive acceleration and prolonged use.
How does vibration dampening extend bearing life?
The Castle M-CC060-0064-00 with vibration dampening and oversized NMB bearings integrates a proprietary dampening system that absorbs shock and reduces mechanical stress on the motor’s internal components. This feature is especially important for large-scale off-road vehicles that encounter uneven terrain and high-impact landings. The oversized NMB bearings are engineered to handle high RPMs and heavy loads, and the dampening system ensures they remain aligned and protected, extending operational lifespan and reducing maintenance.
What makes the stator design ultra-efficient?
The Castle 2028 motor with 12-slot stator and ultra-efficient sensorless mode uses proprietary winding techniques to minimize electrical resistance within the stator assembly. This low-resistance configuration reduces heat buildup and improves energy transfer, resulting in a cooler running motor. Cooler operation not only enhances performance but also prolongs component life, making this motor a reliable choice for extended sessions and demanding terrain.
Is this motor suitable for heavy 1/5 scale RC conversions?
Yes. The Castle 800kV motor for 1/5 RC conversions up to 30 lbs (2WD) and 25 lbs (4WD) is specifically designed to handle the weight and torque requirements of large-scale platforms. Whether you're upgrading a Losi 5IVE-T, DBXL-E, or converting a gas-powered vehicle to electric, this motor delivers the power and control needed for high-performance builds. Its 800kV rating ensures strong acceleration and sustained torque, while the dual sensor ports offer flexible installation across various chassis layouts.
What makes this motor the best Castle upgrade for high-torque acceleration?
The Castle M-CC060-0064-00 2028-800kV sensored brushless motor for 1/5 scale vehicles combines advanced materials, intelligent timing control, and precision engineering to deliver high-torque acceleration with cooler running performance. Its 4-pole, 12-slot design enhances torque output and startup smoothness, while the low-resistance stator and vibration dampening system ensure long-term reliability. This motor is the best Castle upgrade for high-torque acceleration and cooler running performance in large-scale RC builds.
For RC enthusiasts seeking a sensored motor with robust construction and extreme power output, the affordable Castle 2028-800kV motor with 10HP burst output and low-resistance stator offers unmatched value and durability. Buy Castle M-CC060-0064-00 sensored motor for Losi 5IVE-T, DBXL-E, and 1/5 scale builds today.
Product Description of Castle M-CC060-0064-00 2028-800kV sensored brushless motor for 1/5 scale vehicles
The Castle M-CC060-0064-00 2028-800kV sensored brushless motor for 1/5 scale vehicles is engineered to deliver uncompromising torque, cooler running temperatures, and unmatched durability for large-scale RC platforms. Designed for extreme performance, this motor features a robust 4-pole, 12-slot inrunner architecture and dual sensor ports for flexible installation. Whether you're converting gas-powered vehicles or upgrading electric builds, the Castle M-CC060-0064-00 large-scale motor with Kevlar wrap and neodymium magnets is built to withstand the demands of 2WD and 4WD setups weighing up to 30 lbs and 25 lbs respectively. With burst outputs reaching 10 horsepower, this motor is a powerhouse for serious RC enthusiasts.
Key features of the Castle M-CC060-0064-00 2028-800kV motor
- Dual-mode operation – sensored startup and ultra-efficient sensorless running
- Kevlar-wrapped rotor – reinforced for structural integrity under extreme loads
- Neodymium magnets – high-temperature grade for sustained torque delivery
- Vibration dampening – protects oversized NMB bearings for extended life
- Low-resistance stator – cooler operation under heavy throttle conditions
- Dual sensor ports – flexible mounting options for large-scale chassis
How does dual-mode operation enhance performance?
The Castle M-CC060-0064-00 4-pole motor with dual sensor ports and 8mm bullet connectors offers both sensored and sensorless running modes. At startup, the motor uses sensor feedback to eliminate cogging and deliver smooth, torque-rich launches. Once in motion, it transitions seamlessly to Castle’s ultra-efficient sensorless mode, where electronic timing adapts to load conditions. This hybrid approach ensures optimal power delivery and thermal efficiency across all driving phases, making it ideal for high-demand 1/5 scale applications.
Why is the Kevlar wrap critical for rotor integrity?
The rotor in the Castle M-CC060-0064-00 large-scale motor with Kevlar wrap and neodymium magnets is reinforced with high-strength Kevlar to prevent deformation under extreme centrifugal forces. This structural reinforcement is essential for motors operating in the 10HP burst range, where rotational stress can compromise performance. Paired with high-temperature neodymium magnets, the rotor maintains magnetic integrity and mechanical stability even during aggressive acceleration and prolonged use.
How does vibration dampening extend bearing life?
The Castle M-CC060-0064-00 with vibration dampening and oversized NMB bearings integrates a proprietary dampening system that absorbs shock and reduces mechanical stress on the motor’s internal components. This feature is especially important for large-scale off-road vehicles that encounter uneven terrain and high-impact landings. The oversized NMB bearings are engineered to handle high RPMs and heavy loads, and the dampening system ensures they remain aligned and protected, extending operational lifespan and reducing maintenance.
What makes the stator design ultra-efficient?
The Castle 2028 motor with 12-slot stator and ultra-efficient sensorless mode uses proprietary winding techniques to minimize electrical resistance within the stator assembly. This low-resistance configuration reduces heat buildup and improves energy transfer, resulting in a cooler running motor. Cooler operation not only enhances performance but also prolongs component life, making this motor a reliable choice for extended sessions and demanding terrain.
Is this motor suitable for heavy 1/5 scale RC conversions?
Yes. The Castle 800kV motor for 1/5 RC conversions up to 30 lbs (2WD) and 25 lbs (4WD) is specifically designed to handle the weight and torque requirements of large-scale platforms. Whether you're upgrading a Losi 5IVE-T, DBXL-E, or converting a gas-powered vehicle to electric, this motor delivers the power and control needed for high-performance builds. Its 800kV rating ensures strong acceleration and sustained torque, while the dual sensor ports offer flexible installation across various chassis layouts.
What makes this motor the best Castle upgrade for high-torque acceleration?
The Castle M-CC060-0064-00 2028-800kV sensored brushless motor for 1/5 scale vehicles combines advanced materials, intelligent timing control, and precision engineering to deliver high-torque acceleration with cooler running performance. Its 4-pole, 12-slot design enhances torque output and startup smoothness, while the low-resistance stator and vibration dampening system ensure long-term reliability. This motor is the best Castle upgrade for high-torque acceleration and cooler running performance in large-scale RC builds.
For RC enthusiasts seeking a sensored motor with robust construction and extreme power output, the affordable Castle 2028-800kV motor with 10HP burst output and low-resistance stator offers unmatched value and durability. Buy Castle M-CC060-0064-00 sensored motor for Losi 5IVE-T, DBXL-E, and 1/5 scale builds today.
Technical Specifications of Castle M-CC060-0064-00 2028-800kV sensored brushless motor for 1/5 scale vehicles
Brand, Model and Product Type
- Brand: Castle Creations
- Model: M-CC060-0064-00
- Product Type: Castle M-CC060-0064-00 2028-800kV sensored brushless motor for 1/5 scale vehicles, Castle M-CC060-0064-00 4-pole motor with dual sensor ports and 8mm bullet connectors, Castle M-CC060-0064-00 large-scale motor with Kevlar wrap and neodymium magnets, Castle M-CC060-0064-00 with vibration dampening and oversized NMB bearings, Castle 2028 motor with 12-slot stator and ultra-efficient sensorless mode, Castle 800kV motor for 1/5 RC conversions up to 30 lbs (2WD) and 25 lbs (4WD)
Dimensions
- Motor Length: Not specified – designed for large-scale 1/5 RC platforms
- Motor Diameter: Not specified – engineered for high-power applications
- Shaft Diameter: Not specified – compatible with large-scale drivetrain systems
Motor Architecture and Performance
- Motor Type: Sensored brushless inrunner – optimized for large-scale RC builds
- Number of Poles: 4 – enhances torque and startup smoothness
- Stator Configuration: 12-slot – improves efficiency and reduces heat generation
- RPM/Volt (kV): 800 kV – delivers high-torque acceleration for 1/5 scale vehicles
- Burst Output: Up to 10 horsepower – supports short-duration acceleration demands
Materials and Build Quality
- Rotor Construction: Kevlar-wrapped – reinforced for structural integrity under extreme loads
- Magnet Type: High-strength, high-temperature neodymium sintered magnets – resists thermal degradation
- Bearings: Oversized NMB bearings – engineered for high RPM and extended lifespan
- Vibration Dampening: Integrated system – protects internal components and enhances durability
Connectivity and Compatibility
- Sensor Ports: Dual – allows flexible installation in large-scale chassis
- Connector Type: 8 mm bullet connectors – supports high current flow with low resistance
Integrated Technologies
- Running Modes: Sensored startup and ultra-efficient sensorless operation – adapts to load conditions
- Timing Control: Electronic – adjusts automatically for optimal performance across driving phases
Application Suitability
- Ideal for 1/5 scale RC vehicles including Losi 5IVE-T, DBXL-E, and gas-to-electric conversions
- Supports builds up to 30 lbs (2WD) and 25 lbs (4WD) – designed for extreme power and durability
What You Require
- Castle sensored ESC compatible with dual sensor port configuration
- High-capacity battery system suitable for 1/5 scale power demands
Sold Separately
- Castle Link USB adapter for advanced tuning and firmware updates
- Castle sensored ESC required to unlock full performance features
