Product Description of E-flite P-EFLA0880EC5 80A Brushless ESC with switch-mode 8A BEC for sport and scale aircraft

The E-flite P-EFLA0880EC5 80A Brushless ESC with switch-mode 8A BEC for sport and scale aircraft is a high-performance electronic speed controller designed for .40–.90 size electric planes and mid-size helicopters. With support for 3S–6S LiPo and 9–18 cell NiMH/NiCd packs, this ESC delivers 80A continuous current and up to 100A burst, making it ideal for aerobatic flying, cyclic-intensive heli setups, and multi-servo configurations. Its integrated switch-mode BEC powers up to seven analog or six digital servos, eliminating the need for a separate receiver battery and simplifying onboard power management.

Key features of the E-flite P-EFLA0880EC5 80A Brushless ESC

• 80A continuous current – supports high-output brushless motors for sport and scale aircraft
• 100A burst current – handles peak loads during aggressive maneuvers and cyclic spikes
• Switch-mode BEC – delivers 5V @ 5A continuous / 8A peak for multi-servo setups
• Selectable airplane/heli mode – optimized throttle response for fixed-wing and rotorcraft
• Programmable settings – adjust motor braking, timing, throttle range, and startup rate
• Safe power-arm mode – prevents accidental motor starts during setup
• Auto shutdown on signal loss – enhances safety in case of interference or receiver failure
• Finned aluminum heat sink – supports thermal management under sustained load

How does the E-flite P-EFLA0880EC5 support multi-servo aircraft?

The programmable ESC for multi-servo setups with thermal management and aluminum heat sink includes a robust switch-mode BEC capable of powering up to seven analog or six digital servos. This eliminates the need for a separate receiver battery, reducing onboard weight and complexity. Whether you're flying a scale warbird with retracts and flaps or a heli with cyclic and tail servos, the integrated BEC ensures stable voltage delivery across all channels.

What makes this ESC suitable for both planes and helicopters?

The E-flite P-EFLA0880EC5 programmable ESC for .40–.90 size planes and mid-size electric helis features selectable operating modes that tailor throttle response and timing to the demands of each aircraft type. In airplane mode, users can fine-tune motor braking and startup rates for smooth takeoffs and landings. In heli mode, the ESC supports aggressive cyclic loads and precise throttle curves for responsive flight control.

Is this ESC reliable for high-performance flying?

Absolutely. The best programmable ESC with 3–6S LiPo support, 100A burst, and integrated 8A BEC is built for demanding flight profiles. Its thermal management system includes a finned aluminum heat sink to dissipate heat during extended operation, while safety features like auto shutdown and safe power-arm mode protect both pilot and aircraft. With EC5 input and 4.0mm bullet motor leads, installation is secure and straightforward.

Buy E-flite P-EFLA0880EC5 80A ESC for electric fixed-wing aircraft and mid-size helicopters.

Technical Specifications of E-flite P-EFLA0880EC5 80A Brushless ESC with switch-mode 8A BEC for sport and scale aircraft

Brand, Model and Product Type

• Brand: E-flite
• Model: P-EFLA0880EC5
• Product Type: E-flite P-EFLA0880EC5 80A Brushless ESC with switch-mode 8A BEC for sport and scale aircraft, E-flite P-EFLA0880EC5 programmable ESC for .40–.90 size planes and mid-size electric helis, E-flite P-EFLA0880EC5 ESC with 3–6S LiPo support, EC5 input, and 100A burst current, E-flite P-EFLA0880EC5 with 5V @ 5A continuous BEC, 8A peak, and 4.0mm bullet motor leads, Programmable ESC for multi-servo setups with thermal management and aluminum heat sink

Dimensions and Build

• ESC Type: Brushless – Sensorless
• Housing: Finned aluminum heat sink with plastic end caps – supports thermal management
• Operating Modes: Selectable airplane or helicopter mode – optimized for fixed-wing and heli setups

Electrical and Performance Specifications

• Continuous Current Rating: 80A – supports high-output brushless motors
• Burst Current: 100A (15 seconds) – handles peak loads and cyclic demands
• Input Voltage Range: 3–6S LiPo or 9–18 cell NiMH/NiCd – flexible power compatibility

BEC Specifications

• BEC Type: Switch-mode – efficient onboard voltage regulation
• BEC Output: 5V @ 5A continuous / 8A peak – powers up to 7 analog or 6 digital servos

Drive and Control Features

• Programmability: Yes – adjustable motor braking, timing, throttle range, and startup rate
• Safety Features: Safe power-arm mode and auto shutdown on signal loss – prevents accidental motor starts

Connectivity and Compatibility

• Input Connector: EC5 – compatible with high-discharge LiPo battery packs
• Motor Leads: 4.0mm bullet connectors – secure motor connectivity
• Aircraft Compatibility: .40–.90 size sport and scale planes, mid-size electric helicopters

Use Case and Application

• Primary Use: Electric fixed-wing aircraft and mid-size helicopters
• Operational Profile: Multi-servo setups, aerobatic flying, and cyclic-intensive heli maneuvers

What’s in the Box

• 1 × E-flite P-EFLA0880EC5 80A Brushless ESC with Switch-Mode 8A BEC

What You Require / What You Will Need

• Compatible brushless motor – matched to 80A ESC rating
• 3–6S LiPo or 9–18 cell NiMH/NiCd battery – required for operation
• EC5 battery connectors – for secure power delivery

Sold Separately

• Programming interface – for customizing throttle, brake, and timing settings
