Product Description of Castle P-CC010-0155-02 Mamba X ESC and 1406-5700kV sensored motor combo

The Castle P-CC010-0155-02 Mamba X ESC and 1406-5700kV sensored motor combo is engineered for RC enthusiasts who demand high-speed precision and rugged reliability in 1/10 scale platforms. Designed to support 2S to 6S LiPo input, this waterproof system delivers intense acceleration and consistent control across stadium trucks, touring cars, and short course setups. The ESC features SMARTSENSE technology for cog-free launches and seamless transitions to sensorless mode, while the 1406-5700kV motor offers rapid throttle response and efficient torque delivery. Encased in CNC-machined aluminum and potted in epoxy, the Castle P-CC010-0155-02 waterproof ESC with SMARTSENSE and 8A adjustable BEC is built to withstand collisions, jumps, and wet terrain without compromising performance or thermal stability.

Key features of the Castle P-CC010-0155-02 Mamba X ESC and 1406-5700kV sensored motor combo

• SMARTSENSE startup – delivers smooth, cog-free launches and transitions to efficient sensorless mode
• Adjustable 8A BEC – supports high-voltage servo configurations with selectable output range
• Telemetry support – enables live monitoring of ESC temperature, voltage, and RPM
• Data logging – captures real-time performance metrics for post-run analysis and tuning
• Auxiliary wire tuning – allows on-the-fly adjustments to throttle, brake, and torque settings
• Removable 30mm fan – maintains ESC temperature and can be detached for wet terrain use
• Waterproof switch – ensures reliable operation in damp conditions
• CNC aluminum case – enhances durability and heat dissipation
• 4mm bullet connectors – provides secure and low-resistance motor interface
• Electronic brakes – delivers precise deceleration and directional control

How does the Castle P-CC010-0155-02 1/10 scale ESC with telemetry and data logging support improve drivability?

The Castle P-CC010-0155-02 1/10 scale ESC with telemetry and data logging support offers advanced insight into your vehicle’s performance. Enabled by default, the data logging feature records key metrics such as motor RPM, battery voltage, ESC temperature, and throttle input. This information can be downloaded via Castle Link software and used to fine-tune gear ratios, throttle curves, and braking profiles. Telemetry support adds real-time monitoring capabilities when paired with compatible transmitters, helping users avoid overheating and voltage drops during high-demand runs. These features make the combo a powerful tool for racers and hobbyists who want to optimize every aspect of their setup.

Why is the Castle sensored combo with auxiliary wire tuning and electronic brakes ideal for technical driving?

The Castle sensored combo with auxiliary wire tuning and electronic brakes is designed for users who want dynamic control during operation. The auxiliary wire can be programmed to adjust torque control, max throttle, drag brake, and other settings directly from the transmitter. This allows for immediate response to changing terrain or driving conditions without stopping to reprogram. Electronic braking delivers smooth deceleration and directional control, especially useful in tight corners or downhill sections. These features give drivers the flexibility to adapt their setup mid-run and maintain peak performance throughout.

Can the Castle P-CC010-0155-02 with CNC aluminum case and 4mm bullet connectors handle rugged terrain?

Yes, the Castle P-CC010-0155-02 with CNC aluminum case and 4mm bullet connectors is built to endure the physical demands of off-road driving. The CNC-machined aluminum housing not only protects the ESC’s internal components but also acts as a heat sink, dissipating thermal buildup during extended runs. The epoxy potting adds an extra layer of waterproofing and impact resistance, making the ESC suitable for wet grass, mud, and rocky trails. The 4mm bullet connectors ensure a secure and low-resistance connection between motor and ESC, supporting consistent power delivery even under aggressive throttle inputs.

What makes the Castle brushless ESC with removable 30mm fan and waterproof switch a reliable upgrade?

The Castle brushless ESC with removable 30mm fan and waterproof switch offers both thermal management and environmental protection. The 30mm fan helps regulate ESC temperature during high-load operation and can be removed for wet terrain use to prevent water damage. The waterproof switch ensures reliable power control even in damp conditions, adding convenience and durability to the overall system. These features make the Mamba X combo a dependable upgrade for users who drive in unpredictable environments and need electronics that can keep up with their pace.

Is the Castle P-CC010-0155-02 Mamba X ESC and 1406-5700kV sensored motor combo suitable for competitive setups?

Absolutely. The Castle P-CC010-0155-02 Mamba X ESC and 1406-5700kV sensored motor combo is designed for precision and power. SMARTSENSE technology ensures smooth, predictable launches and transitions to sensorless mode for efficient high-speed performance. The adjustable BEC supports a wide range of servo voltages, making it compatible with both standard and high-voltage configurations. These features, combined with telemetry support and data logging, give competitive drivers the tools they need to fine-tune their setup and stay ahead of the curve. Whether you're racing on-road or navigating technical terrain, the Mamba X delivers consistent control and responsiveness.

Why is this the affordable Castle ESC with SMARTSENSE startup and Castle Link programming?

The affordable Castle ESC with SMARTSENSE startup and Castle Link programming offers premium features at a competitive price point. SMARTSENSE ensures cog-free launches and efficient transitions, while Castle Link programming gives users access to a wide range of tuning parameters. The included coupon for a Castle Link USB adapter makes it easy to get started, and firmware updates are available at no additional cost. These features make the Mamba X a smart investment for hobbyists who want reliability, flexibility, and long-term value in their electronics setup.

For RC enthusiasts seeking a powerful, configurable, and telemetry-ready brushless system, the Castle P-CC010-0155-02 Mamba X ESC and 1406-5700kV sensored motor combo delivers unmatched control and performance. Buy Castle P-CC010-0155-02 ESC combo for 2WD stadium trucks and touring cars.

Technical Specifications of Castle P-CC010-0155-02 Mamba X ESC and 1406-5700kV sensored motor combo

Brand, Model and Product Type

• Brand: Castle
• Model: P-CC010-0155-02
• Product Type: Castle P-CC010-0155-02 Mamba X ESC and 1406-5700kV sensored motor combo, Castle P-CC010-0155-02 waterproof ESC with SMARTSENSE and 8A adjustable BEC, Castle P-CC010-0155-02 1/10 scale ESC with telemetry and data logging support, Castle P-CC010-0155-02 with CNC aluminum case and 4mm bullet connectors, Castle brushless ESC with removable 30mm fan and waterproof switch, Castle sensored combo with auxiliary wire tuning and electronic brakes

Dimensions

• ESC Length: 5.44 cm – compact footprint for 1/10 scale chassis integration
• ESC Width: 3.52 cm – fits standard electronics trays with minimal space impact
• ESC Height: 3.0 cm – includes removable 30mm cooling fan for thermal regulation
• ESC Weight: 101 g – potted design for durability and moisture resistance
• Motor Shaft Diameter: 3.17 mm – compatible with standard gear interfaces

Power and Voltage Specifications

• Input Voltage Range: 2S–6S LiPo – supports high-voltage setups for extreme performance
• BEC Output: Adjustable – 5.25V to 8.0V with 8A peak current
• BEC Type: Integrated – housed within ESC for compact design

Cooling and Durability

• Cooling System: Removable 30mm fan – maintains ESC temperature during high-load operation
• ESC Housing: CNC-machined aluminum case – enhances heat dissipation and structural integrity
• Waterproof Rating: Water-resistant epoxy-potted ESC – protects electronics from moisture exposure

Motor Specifications

• Motor Type: Brushless sensored – inrunner design for efficient torque delivery
• Kv Rating: 5700Kv – optimized for high-speed 1/10 scale applications
• Motor Configuration: 4-pole, 12-slot – delivers smooth startup and consistent torque

Connectivity and Interfaces

• Connector Type: 4mm bullet connectors – ensures secure motor-to-ESC interface
• Programming Interface: Castle Link USB or Bluetooth – supports advanced tuning and firmware updates

Control and Operation Modes

• Auxiliary Wire: Programmable – allows on-the-fly tuning of throttle, brake, and torque settings
• Drive Mode: Forward/Brake/Reverse – supports full directional control
• Programming Options: Transmitter-based or via Castle Link Suite – enables full customization
• Timing Advance: Electronic – adjusts automatically for optimal efficiency across load conditions

Diagnostics and Feedback

• Audible Alerts: Yes – notifies users of calibration issues and error conditions

Telemetry and Data Logging

• Telemetry Ready: Yes – compatible with Castle telemetry devices and supported transmitters
• Data Logging: Enabled by default – records performance metrics for post-run analysis

Vehicle Compatibility

• Supported Platforms: 1/10 scale 2WD stadium trucks, touring cars, and short course setups
• Extended Compatibility: Select 1/8 scale race buggies (as per manufacturer guidance)

What’s in the Box

• 1 × Castle Mamba X ESC with Sensor Harness
• 1 × Castle 1406-5700kV sensored brushless motor
• 1 × Coupon for Castle Link USB adapter
• 1 × Mamba Decal Sheet
• 1 × Driver’s Ed and Quick Start Guide
• 1 × Gearing Chart for Castle Motors

What You Require / What You Will Need

• Castle Link USB or Bluetooth adapter for programming (sold separately)
• Castle telemetry device for real-time monitoring (sold separately)

Sold Separately

• Castle Link USB adapter
• Castle B-Link Bluetooth adapter
• Castle telemetry device
